Fully Automatic Cleaning System for 50L–1000L Chemical Drums

Fully Automatic Cleaning System for 50L–1000L Chemical Drums by CYCO revolutionizes industrial container hygiene. This integrated, one-touch system automates the entire process—loading, internal/external cleaning (with 360° 3D spray), water control, disinfection, and unloading—cleaning each drum in just 1-2 minutes. Featuring a PLC touch panel, optional pressures up to 1000 bar, and additional modules for drying, leak detection, and explosion-proofing, it delivers thorough, dead-angle-free cleaning with minimal liquid use. Ideal for the chemical, pharmaceutical, food, and personal care industries, this solution dramatically boosts efficiency, ensures consistent hygiene standards, and enhances operational safety.

Categories: Cleaning Equipments, IBC Tank Cleaning Equipments

The CYCO 50L–1000L chemical drum cleaning system provides fully automated internal and external cleaning of chemical raw material drums, significantly improving production efficiency with one-touch operation and a high level of automation.

Product Features

This fully automatic system is operated via a PLC touch control panel and supports automatic loading, cleaning, water control, disinfection, and unloading.

Cleaning each drum takes only 1–2 minutes on average, greatly enhancing operational efficiency.

Equipped with a precision 360° three-dimensional spray head that delivers powerful cleaning with minimal liquid consumption, ensuring thorough, dead-angle-free cleaning.

Optional cleaning pressure from 2 to 1000 bar is available to meet various industrial cleaning requirements.

The system features automatic drum detection, flipping mechanism, auto-opening doors, and more — easy to operate with stable performance.

System Components

External Cleaning System: Cleans the outer surface of the drum.

Drying System: Dries drums after cleaning.

Disinfection System: Disinfects drums to ensure hygienic standards.

Water Heating System: Adjusts water temperature to improve cleaning effectiveness.

Leak Detection System: Checks drums for water leakage.

Explosion-Proof Configuration: Ensures safe operation in hazardous environments.

Working Process

Loading: The operator places the drum on the cleaning conveyor and initiates the system.

Cleaning: The conveyor transports the drum into the cleaning chamber, the automatic door closes, and the drum is flipped 180° while internal and external cleaning begins.

Water Control & Disinfection: After cleaning, the drum undergoes water control (drainage) and disinfection treatment.

Unloading: The automatic door opens, and the drum is conveyed to the next station for unloading.

Applications

This system is widely used in the catering, food, pharmaceutical, personal care, and chemical industries, especially in scenarios requiring cleaning of 50L to 1000L chemical drums.
