Automatic Water Tank Cleaning Equipment

Automatic Water Tank Cleaning Equipment from CYCO is a stainless-steel automated cleaning solution designed for thorough internal sanitation of water tanks in various shapes and sizes. Using a PLC-controlled system, it automatically extends and rotates a high-pressure cleaning unit to remove dirt, moss, and impurities from tank walls while simultaneously dispersing disinfectant for combined cleaning and disinfection. Its 3D extension and rotation mechanism ensures no dead spots, improving cleaning efficiency and safety with minimal manual intervention. Adjustable high-pressure jets provide complete internal coverage, and the advanced design enhances reliability and reduces operational risk in industrial and commercial environments.

Categories: Cleaning Equipments, Other Cleaning Equipments

Working Principle

The system uses a PLC control unit to drive the cleaner for automatic extension and rotation, ensuring comprehensive internal cleaning of the water tank.

While extending and rotating, the device sprays high-pressure water jets that effectively dislodge and clean dirt, moss, and other impurities from the tank walls.

During the cleaning process, a disinfection unit releases disinfectant, which mixes with the cleaning water jet, achieving simultaneous cleaning and disinfection.

Main Features

The cleaner can extend and rotate in three-dimensional space, ensuring there are no dead spots during cleaning.
High-pressure water jets combined with disinfectant improve cleaning efficiency and ensure thorough cleaning.
The PLC control system allows presetting of cleaning cycles and times, automating the entire cleaning process.
Advanced electrical design ensures safe and reliable operation, reducing human error and operational risks.

Technical Parameters

Material: Typically made of SUS304 or SUS316L stainless steel to ensure corrosion resistance and long service life.
Connection Type: Threaded or quick-connect fittings for easy installation and removal.
Specifications: DN25–50, suitable for cleaning water tanks of different sizes.
Working Pressure: PN0.3–100 MPa, ensuring effective high-pressure cleaning.
Working Temperature: ≤120°C, adaptable to various environmental cleaning conditions.
Rinsing Radius: ≥2.5 meters, ensuring complete coverage of the water tank interior.
Rotation Speed: 2–16 rpm, adjustable according to cleaning requirements.
